Product Description

Features

Jatoba Fretboard

Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.

Mono-unit output jack

The mono-unit output jack is made of solid, durable material and is a single piece to avoid unwanted movement and loosening of the jack, which leads to contact failure or disconnection. This innovation allows for long term playing enjoyment and minimal maintenance.

F106 bridge

The F106 bridge enriches sustain. String height adjustment can be done easily and independently.

Neck-through Construction

Neck-through construction provides massive sustain and playing comfort.

Wizard III 5pc Maple/Walnut neck

Ibanez's thin, flat and fast Wizard neck is strong and sturdy and offers unlimited playability and features a two-octave 24-fret fretboard for a wide tonal range.

Quantum H-H pickups

The Quantum pickups provide accelerated bass response for exceptionally fast tracking of high-speed staccato riffing with crushing mid range and precise high-end articulation.

    SPECS

• Neck Type: Wizard III 5-piece Maple/Walnut Neck-Through
• Top/Back/Body: Nyatoh Wing Body
• Fretboard: Jatoba fretboard/White Dot Inlay
• Frets: Jumbo Frets
• Number of Frets: 24
• Bridge: F106 Bridge
• String Space: 10.5mm/.413"
• Neck Pickup: Quantum (H) Neck Pickup (Passive/Ceramic)
• Bridge Pickup: Quantum (H) Bridge Pickup (Passive/Ceramic)
• Factory Tuning: 1E,2B,3G,4D,5A,6E
• Strings: D'Addario® EXL110
• String Gauge: .010/.013/.017/.026/.036/.046
• Hardware Color: Black

    NECK DIMENSIONS

• Scale: 648mm/25.5"
• Width at Nut: 43mm/1.69"

• Width at 24th Fret: 58mm/2.28"
• Thickness at 1st Fret: 19mm/0.75"
• Thickness at 12th Fret: 21mm/0.83"
• Radius: 400mm/15.75"
